System
* Hot Runner System
* Cold Runner System
* Low-Bed Design
* High-Bed Design
Feature
*To avoid scorch rubber remaining inside barrel
*Easy to change rubber compound and not waste rubber
*Suitable for all kinds of rubber compound, silicone rubber and viton.
Model
Machine Specification
| Clamping Force(ton) |
Injection Volume(c.c) |
Heating Platen size(mm) |
Injection Pressure (kg/cm²) |
Injection Temp. Control(set) |
Motor |
| 100 | 500 1000 |
405x430 | 1900 | 2 | 15HPx6P |
| 200 | 1000/1500 | 550x550 | 1900 | 2 | 20HPx6P |
| 250 | 2000/2500 | 650x650 | 1900 | 2 | 20HPx6P |
| 350 | 2500 3500 |
700x700 | 1900 | 2 | 25HPx6P |
| 500 | 3000/4000 | 850x850 | 1900 | 2 | 25HPx6P |
| Clamping Force(ton) |
Daylight (mm) |
Stroke of Main Ram(mm) |
Screw Diameter(mm) |
Barrel Diameter(mm) |
Screw Length/ Diameter:L/D |
| 100 | 350-450 | 350 | Ø35 Ø40 |
Ø65 Ø80 |
15:1 |
| 200 | 400-550 | 450 | Ø40 | Ø80 | 15:1 |
| 250 | 400-550 | 450 | Ø40 | Ø80 | 15:1 |
| 350 | 400-550 | 450 | Ø40 Ø50 |
Ø80 Ø100 |
15:1 |
| 500 | 400-550 | 450 | Ø50 | Ø100 | 15:1 |
OPTION:
1.Upper ejector(lifter)
2.Bottom ejector (lifter)
3.Bottom mold is allowed to shuttle out 70% for outside bottom ejector lifting up the final parts
4.2RT
5.3RT
6.Outside top and bottom ejectors
7.Middle mold turn 180 degree
8.Cold Runner mold system
9.Waste-less technology
10.Silicone Stuffer
11.For other mold open system, please refer to P.24(Click)
OPTIONAL
