Model
Machine Specification
| F.I.F.O. | Clamping Force(ton) |
Injection Volume(c.c) |
Heating Platen size(mm) |
Injection Pressure (kg/cm²) |
Injection Temp. Control(set) |
Motor | |
| 15 | 50 | 430x250 | 2100 | 1 | 5HPx4P | ||
| 30 | 100 | 400x300 | 2100 | 1 | 7.5HPx4P | ||
| 50 | 200 | 450x300 | 2100 | 1 | 10HPx6P | ||
| 80 | 250 | 450x350 | 2100 | 1 | 10HPx6P | ||
| Clamping Force(ton) |
Daylight (mm) |
Stroke of Main Ram(mm) |
Min. Mold Height(mm) |
Screw Diameter(mm) |
Barrel Diameter(mm) |
Screw Length/ Diameter:L/D |
|
| 15 | 350 | 300 | 50 | Ø30 | Ø22.5 | 12:1 | |
| 30 | 350 | 300 | 50 | Ø30 | Ø30 | 12:1 | |
| 50 | 350 | 300 | 50 | Ø30 | Ø40 | 12:1 | |
| 80 | 350 | 300 | 50 | Ø30 | Ø40 | 12:1 | |
| F.I.L.O. | Clamping Force(ton) |
Injection Volume(c.c) |
Heating Platen size(mm) |
Injection Pressure (kg/cm²) |
Injection Temp. Control(set) |
Motor | |
| 15 | 50 | 430x250 | 1100 | 1 | 5HPx4P | ||
| 30 | 100 | 400x300 | 1100 | 1 | 5HPx4P | ||
| 50 | 200 | 450x300 | 1100 | 1 | 7.5HPx4P | ||
| Clamping Force(ton) |
Daylight (mm) |
Stroke of Main Ram(mm) |
Min.Mold Height(MM) |
Screw Diameter(mm) |
Barrel Diameter(mm) |
Screw Length/ Diameter:L/D |
|
| 15 | 350 | 300 | 50 | Ø30 | Ø22.5 | 12:1 | |
| 30 | 350 | 300 | 50 | Ø30 | Ø30 | 12:1 | |
| 50 | 350 | 300 | 50 | Ø30 | Ø40 | 12:1 | |
OPTION:
1.Upper ejector(lifter)
2.Bottom ejector(lifter)
3.Bottom mold is allowed to shuttle out 70% for outside bottom ejector lifting up the final parts
